Cnc Chip Removing Conveyor System

The machining process produces a large amount of chips, which often contain large amounts of oil and cutting emulsions. Due to the fluffy swarf, it is easy to be scattered on the machine tool and the workshop channel, so it is not only difficult to clean, but also seriously pollutes the workshop environment. The traditional solution is to manually clean and finally collect the chips into a large chip box, and use the crane to hoist the chip box to the car on a regular basis. This method is labor-intensive, wastes manpower, and takes up The crane used for production is easy to conflict with production, and the chip storage area of the workshop will occupy an effective workshop area and affect the workshop logistics. At the same time, it also causes management difficulties, and the wide application of CNC machine tools with the development of production. The machining efficiency of the workpiece has been greatly improved, but the corresponding research on the chip removal of the machine tool is relatively lagging. And now most of the research on chip removal is only for a single machine tool, and rarely involves the design of the entire workshop. To this end, our company designs a solution for the entire shop chip removal system.
